Experience the benefits of the Mistral MA1200 patient warming system, including:
Comes with 2 sets of washable blankets (2 Small, 2 Medium and 2 Large)
| General specifications | |
| Article number | MA1200-EU |
| Rated voltage | 220-240 V~ |
| Frequency | 50/60 Hz |
| Device sound pressure | 48 dBA |
| Average current | 3.2 A |
| Peak current | 9.0 A |
| Peak power | 1000 VA |
| Average power at 43°C and tamb 22 +/- 1.5°C | 750 VA / 600 W |
| Fuses | 6.3AHF/250V~ |
| Air flow rate at nominal | 86 – 101 [Nm³/h], 50 – 59 |
| voltages and ambient | [CFM] (MA1200-QC-EU: 60 – |
| temperature (1.8 m hose ) | 101 [Nm³/h], 35 – 59 [CFM]),
(depending on orientation of the hose, supply voltage, type and drape of the blanket) |
| GMDN code | 36954 (circulating-air whole-body heating system control unit) |
| Dimensions | 16 cm x 35 cm x 40 cm (l x w x h) |
| Weight | 5.2 kg |
| Hose length | 1.8 m (3 m hose optional) |
| Power supply cord length | 4.0 m |
| Filtration | HEPA H13 class filter, conform EN 1822-1:2009 |
| Classification93/42/EEC | Class IIb |
| Classification IEC 60601-1 | class I, Body Floating (BF) |
| Overvoltage category according to IEC 60664-1
|
Category II |
| Classification IEC 60529 | IP23 |
| Setpoint temperature | Ambient air, 32°C, 38°C, 43°C |
| Accuracy of temperature at the end of the hose | ± 2.5 °C (under all validated operating environmental conditions) |
| Setpoint reached after | Under 30 seconds |
| Low temperature limit | 10°C |
| Maximum average contact surface temperature | 45.5°C (Compliant with IEC 80601-2-35)
|
| High temperature safety limit | < 56°C (Compliant with IEC 80601-2-35)
|
| Auditory alarm signal sound pressure | 80 dBA |
| Applicable technical standards | IEC 60601-1:2005+A1:2012, IEC 80601-2-35:2016 |
| Expected lifetime device | 7 years |
| Expected lifetime hose | 1 year |
| The essential performance of the Mistral-Air Warming System is: when supplying air to the patient “the Maximum CONTACT SURFACE TEMPERATURE” must be below the safe temperature limits according to IEC 80601-2-35: 2009 + C1:2012 +C2:2015, Clause 201.11.1.2.1.102. | |
| Validated operating environmental specifications | |
| Ambient temperature | 15°C to 30°C |
| Relative humidity | 30% to 75% |
| Validated transport and storage specifications | |
| Ambient temperature | -20°C to 70°C |
| Relative humidity | 10% to 90% (non-condensing) |
| Atmospheric pressure | 50 kPa to 106 kPa |
