CXDI-Elite Series Wireless Digital Radiography Systems
Canon’s latest generation of wireless flat panel detectors takes you to new heights of possibility in digital radiography. Offering exceptional image quality, thoughtful design, and intuitive features, the CXDI-Elite Wireless Series is the ideal choice for mobile applications or general X-ray needs.
CXDI-Elite Series Panels
The new CXDI-Elite Series Panels are purpose-built to meet the demands of modern medical imaging departments. With a focus on usability, durability, and both user and patient comfort, these panels offer:
Intelligent Noise Reduction (NR) Software
Canon’s Intelligent Noise Reduction (NR) software uses deep learning and artificial intelligence to minimise noise in X-ray images. Trained on a database of approximately 3,000 images, this advanced tool supports more accurate diagnoses and allows for high-quality imaging at reduced radiation doses. Sold separately.
Sleek Detector Design
Designed with both patient and practitioner in mind:
| Model Name | CXDI-720C Wireless |
| Purpose | General Radiology |
| Method | Flat Panel Detector: Scintillator and Amorphous Silicon (a-Si) |
| Scintillator | Cesium Iodide |
| Weight (including battery) | 2.3kg |
| Effective Imaging Area | 350 × 426 mm |
| External Dimensions | 384 × 460 × 15 mm |
| Image Matrix Size | 2800 × 3408 pixels |
| Pixel Size | 125 μm |
| Limiting Resolution | 4.0 lp/mm |
| Greyscale | A/D: 16 bit |
| DQE | Typical 74% (0 lp/mm), 67% (0.5 lp/mm) |
| MTF | Typical 45% (2 lp/mm) |
| Time Until Ready | 3 seconds |
| Preview Image Time | 1 second |
| Cycle Time | 4 seconds |
| Dust, Water Resistance Rating | IP57 (for dust protection and submersion in water up to 1 metre for 30 minutes) |
| Battery Performance – Generator Connection Mode | Maximum 2,000 images @ 4 sec cycle; average 160 images @ 100 sec cycle |
| Battery Performance – Automatic Exposure Detection Mode | Maximum 1,900 images @ 4 sec cycle; average 145 images @ 100 sec cycle |
| Charging Performance | Battery charging time approx. 150 minutes |
| Wireless Standard | IEEE802.11ac |
| Wireless Channel/Band | 2.4 GHz, 5 GHz |
| Optional Function Compatibility | Built-in AEC Assistance, Intelligent NR, Scatter Correction |
